1. Meet the high efficient loading and unloading operation.
2. Flexible, rapid and high efficiency.
3. OEM and ODM Service available.
4. Warranty: 12 months warranty , beyond the warranty period.
Small loader is one of the main types of earthwork construction in engineering construction. Series bucket meets the needs of different materials and mining. Strength and durability of chassis and movable arms. The quality guarantee period of the main parts is one year. Small loader has the advantages of light weight, fast speed, flexibility, high efficiency, not easy to damage the road surface, large grounding voltage and so on. Higher production efficiency and lower preservation costs. There is a huge barrel and a shorter transfer arm. Hydraulic inspection system. Small turning radius, large Angle. Tripod structure, front frame, simple and stable operation. Can meet the emission requirements of different countries. Different assistive devices can be selected to achieve different functions. Pressure gauge ports should be used to effectively eliminate faults.
Detail
Specification
Basic performance parameters | |
Total Weight(kg) | 2340 |
Rated bucket capacity(m3) | 0.6 |
Maximum travel speed(km/h) | 0-6.4 |
Gradeability(%) | 25 |
Rated loading quality(kg) | 600 |
Hydraulic tank(L) | 28 |
Fuel tank(L) | 15 |
Maximum discharge height(mm) | 2025 |
Discharge distance(mm) | 650 |
Bucket lift time is full(s) | 8 |
Bucket falling time(s) | 4 |
Minimum clearance from the ground(mm) | 155 |
Minimum turning radius(m) | 2.4 |
Engine | |
engine model | Perkins |
Rated speed(r/min) | 2200 |
rated power(kw) | 14.7 |
Application
The loader is mainly used for shoveling, loading, unloading, transporting soil and stone materials of a kind of bulk materials, but also for rock, hard soil for light shovel digging operations. If the work device is different, it can also complete the work of pushing earth, lifting and loading and unloading other materials. In highway construction, it is mainly used for filling and digging of roadbed engineering, aggregate and loading of asphalt and cement concrete material yard. Because it has the advantages of fast operation speed, good mobility and light operation, it has become the main machinery in earthwork construction.
A loader is a heavy system gadget utilized in construction to move or load materials which includes soil, rock, sand, demolition particles, and so forth. into or onto every other form of machinery including a sell off truck, conveyor belt, feed-hopper, or railroad car.
