1. Meet the high efficient loading and unloading operation.
2. Flexible, rapid and high efficiency.
3. OEM and ODM Service available.
4. Warranty: 12 months warranty , beyond the warranty period.
Small loader is one of the main types of earthwork construction in engineering construction. Series buckets meet the needs of different materials and mining. Strength and durability of chassis and movable arm. The warranty period of main parts is one year. Small loader has the advantages of light weight, fast speed, flexibility, high efficiency, not easy to damage the road, large grounding voltage and so on. Higher production efficiency and lower storage cost. There is a huge barrel and a short transfer arm. Check the hydraulic system. Small turning radius and large angle. Tripod structure, front frame, simple and stable operation. It can meet the emission requirements of different countries. Different auxiliary devices can be selected to realize different functions.
Detail
Specification
Basic performance parameters | |
Total Weight(kg) | 2340 |
Rated bucket capacity(m3) | 0.6 |
Maximum travel speed(km/h) | 0-6.4 |
Gradeability(%) | 25 |
Rated loading quality(kg) | 600 |
Hydraulic tank(L) | 28 |
Fuel tank(L) | 15 |
Maximum discharge height(mm) | 2025 |
Discharge distance(mm) | 650 |
Bucket lift time is full(s) | 8 |
Bucket falling time(s) | 4 |
Minimum clearance from the ground(mm) | 155 |
Minimum turning radius(m) | 2.4 |
Engine | |
engine model | Perkins |
Rated speed(r/min) | 2200 |
rated power(kw) | 14.7 |
Application
Loader is mainly used for shoveling, loading, unloading and transporting bulk materials of earth and stone materials. It can also be used for light shovel excavation of rock and hard soil. If the working devices are different, it can also complete the work of bulldozing, lifting and loading and unloading other materials. In highway construction, it is mainly used for filling and excavation of subgrade engineering, aggregate and loading of asphalt and cement concrete stockyard. Because it has the advantages of fast operation speed, good mobility and light operation, it has become the main machinery for earthwork construction.
Loader is a kind of heavy system equipment, which is used to move or load materials in buildings, including soil, rock, sand, blasting particles, etc. Enter or enter any other form of machinery, including the sale of trucks, conveyor belts, feed hoppers or railway cars.
